Customized 10T/H Wheat Starch Airflow Flour Drying Machine
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | DG-3.2 DG-4.0 DG-6.0 DG-10.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Product Name: | Flour Drying Machine | Useful Life: | 20 Years |
|---|---|---|---|
| Capacity: | 10 T/h | Advantage: | High Efficiency |
| Customized: | Customized | Condition: | New |
| Power: | 139 Kw | Installation: | Yes |
| High Light: | 10T/H Airflow Flour Drying Machine,Flour Drying Airflow Dryer,139Kw Wheat Starch Machine |
||
Product Description
Wheat Starch Machine Airflow Dryer Flour Drying Making Equipment
1.Description of airflow dryer
Airflow dryer is widely used for powdery drying, and the humidity is controlled between 14% and 20%.
Main technical parameters
| Model | DG-3.2 | DG-4.0 | DG-6.0 | DG-10.0 |
| Output(t/h) | 3.2 | 4.0 | 6.0 | 10.0 |
| Power capacity(Kw) | 97 | 139 | 166 | 269 |
| Moisture of wet starch(%) | ≤40 | ≤40 | ≤40 | ≤40 |
| Moisture of dry starch(%) | 12-14 | 12-14 | 12-14 | 12-14 |
The working principle of airflow dryer
The cold air enters the radiator plate through the air filter, and the hot air flow after heating enters the dry air pipe. Meanwhile, the wet material enters the hopper of the feeding unit from the wet starch inlet, and is transported into the hoist by the feeding winch.The hoist rotates at high speed to drop the wet material into the dry duct, so that the wet material is suspended in the high speed hot air stream and heat is exchanged.After the material is dried, it enters the cyclone separator with the airflow, and the separated dry material is discharged by wind winding, and the finished product is screened and packed into the warehouse. And the separated exhaust gas, by the exhaust fan into the exhaust gas duct, into the atmosphere.
2.Packing & Shipping
Packing & Shipping: Customize the wooden case according to the size of the product.
Delivery: 14 days after receiving pre-payment (on time according to contract strictly).
3.FAQ
Q1: Can you provide detailed parameters and drawings of the equipment?
A: Yes, you can contact us by email, we will provide you with the detailed parameters and drawings of the equipment.
Q2:How long is the warranty period of the eq uipment?
A:After the successful installation and commissioning of the equipment, there is a one-year warranty period.
Q3:What kind of after-sales service do you provide?
A:Provide after-sales service for customers through telephone, video guidance, on-site maintenance, etc.
Q4: Are your products can be assured ?
A: Our machines are all passed ISO9001:2001 and have CE certificate by SGS, TUV.
Q5: If we show you our layout of factory, can you help us to design the whole process line?
A : Yes, our experienced engineers and technical employees can help you to arrange the layout and installation of whole process line based on your real situation;
Q6: If we have samples of new products, can you help us to analysis and design the machine?
A: Yes, Our technical department can help you to analysis, design and test the new products you offered.
