1200r/Min 50t/H 37Kw Peeled Cassava Grinder Machine
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | DPS5050 DPS5076 DPS50100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 10 sets/month |
|
Detail Information |
|||
| Product Name: | Cassava Cutting Machine | Line: | Garri Processing Line |
|---|---|---|---|
| Useful Life: | 20 Years | Dimension: | 1530*1250*665 Mm |
| Capacity: | 10-50 T/h | Power: | 37Kw |
| Diameter Of Rotor: | 480 Mm | Service: | Overseas Installation |
| Speed Of Rotor: | 1200 R/min | Warranty: | 1 Years |
| High Light: | Peeled Cassava Grinder Machine,50t/H Cassava Grinder Machine,1200r/Min Garri Processing Equipment |
||
Product Description
High Effective Peeled Cassava Cutting Grinder Machine Garri Processing Equipment
1.Description of garri processing equipment
Zhengzhou Jinghua Industry Crusher is newly designed with compact structure, easy disassembly and low maintenance cost. The machine is widely used for cracking big materials. The raw material is usually fresh cassava tube, fresh sweet potato and after crushing you can get the finished product with a 20-30mm size. It is a precrushing.
Advantages of cassava cutting machine
1.In dependent research and development,integrate with the same kind so fequipment performance from local and abroad manufactures, and combined with our many years useing esperience.
2.Newly designed with compact structure,easy disassembly and low maintenance cost.
3.Small volumes with large capacity,medium speed,low energy consumption and steady operation.
4.To avoid duplication of material cutting and improvge cutting ability.Blade is sepcially made and is durable.
Main technical parameters
| Model |
Diameter of rotor (mm) |
Speed of rotor (r/min) |
Blade Number |
Rotor length (mm) |
Power (Kw) |
Dimension (mm) |
Weight (Kg) |
Capacity (t/h) |
| DPS5050 | Φ480 | 1200 | 9 | 550 | 7.5/11 | 1030x1250x665 | 650 | 10-15 |
| DPS5076 | Φ480 | 1200 | 11 | 760 | 11/15 | 1250x1300x600 | 750 | 15-30 |
| DPS50100 | Φ480 | 1200 | 15 | 1000 | 18.5/22 | 1530x1250x665 | 900 | 30-50 |
| DPS60100 | Φ580 | 1200 | 15 | 1000 | 30/37 | 1530x1400x765 | 1100 | 60-80 |
Working principle of crusher
The main working part of the crusher is a rotary table with a blade. The rotary table is composed of a spindle and a rotary table.The motor drives the rotary table to rotate at a medium speed in the slicing chamber, and the material enters from the upper feeding port,the upper part of the rotary knife is sheared by the rotary blade and is discharged at the lower part of the rotary knife.
2.Company Information
Jinghua company is a specialized engineering technology company specializing in various starch engineering design, equipment manufacturing, engineering installation and debugging, technical personnel training and other work. Has two modern large factory, engineering and technical personnel more than 30 people, can provide installation services overseas. Our company has undertaken national and provincial scientific research projects.,with more than 30 invention patents, various honor certificate more than 20.The chairman of the board is professor wang yanbo, who is mainly engaged in theoretical research on the transformation and utilization of grain resources, teaching, scientific research and engineering design of starch and its deep processing direction, and research and development of modern equipment. He has published 7 scientific works, 6 national standards and 30 academic papers.
3.Our Service
Pre-sale service
1.Introducing detail features and application of the products to customer.
2.Selecting economical and practical machines for customer.
3.Providing operation data of the related machine.
4.Providing means of trial performance for customer.
5.Flow chart and factory designing layout.
Sale service
1.Recommending engineering conditions required for installation of the machine.
2.Communicating the manufacturing progress of machines with customer in time.
3.Project planning and design services.
After-sale service
1.Training of equipment maintenance and operating personally.
2.Installation and commissioning of equipment until everything is functional.
3.One year warranty and providing long-term maintenance service and spare parts.
4.Giving technical support to customer for developing new product.
5.Engineers available to serve machinery overseas.
