1000sqm Maize Corn Starch 20t/H 37Kw Pipe Bundle Dryer
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | GZG60 GZG100 GZG300 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Product Name: | Pipe Bundle Dryer | Line: | Corn Starch Production Line |
|---|---|---|---|
| Useful Life: | 20 Years | Condition: | New |
| Customized: | Customized | Weight: | 9000 Kg |
| Power: | 37 Kw | Capacity: | 20 T/h |
| High Light: | 37Kw Pipe Bundle Dryer,20t/H Pipe Bundle Dryer,1000sqm Maize Starch Drying Machine |
||
Product Description
Large Capacity 37 Kw Pipe Bundle Dryer Maize Starch Dring Making Machine
1.Description of corn starch drying machine
Pipe bundled tube dryer is an indirect heating dryer. It may operate either on countercurrent or down current principals. It can be widely applied in corn starch processing just like drying corn germ, cornfiber and corn protein.The machine has virtues of low steam consumption, big production quantity, low noise and less occupied area.The drying area of from 40sqm to 1000sqm.
Working principle
Using the principle of heat conduction and radiation, the material is transported into the dryer by screw.Under the agitation of rotating tube bundle copying plate, it moves from the feeding end to the feeding end, and absorbs heat and loses water during the movement. The dryer is in a negative pressure state during production.The steam direction is opposite to the material direction, the energy saving effect is good, in the starch industry used for drying germ, fiber, gluten.
Main technical parameters
| Materials | Germ | Corn fiber | Corn protein |
| Inlet water content | 55% | 60% | 45% |
| Outlet water content | 3~5% | 10~12% | 12~13% |
| Drying intensity (evaporation kg water/ m2) | 2.5~3 | 4.8 | 4.7 |
| Model | Outline dimension | power(kw) | Weight (T) |
| GZG60 | 6100*1600*2160 | 5.5 | 9 |
| GZG100 | 7800*1900*2460 | 7.5 | 13.5 |
| GZG150 | 7100*2200*2750 | 11 | 19.5 |
| GZG300 | 8800*2460*3180 | 18.5 | 26.5 |
| GZG500 | 10980*2900*4000 | 37 | 50 |
| GZG650 | 11190*3200*4300 | 55 | 67 |
| GZG1000 | 11800*3660*4770 | 110 | 91 |
2.Packing & Shipping
Packing : Customize the wooden case according to the size of the product.
Delivery: 14 days after receiving pre-payment (on time according to contract strictly).
3.Why Choose Us
Zhengzhou jinghua industrial co., LTD., as a member of China starch industry association, was invited to attend the 2019 Shanghai international starch and starch derivatives exhibition. In this meeting, zhengzhou jinghua industry co., ltd. and the new and old customers in-depth meeting exchanges, for the future further cooperation to create a good beginning, to the whole industry to show the recent new research and development results, harvested from more peers and experts unanimously recognized.
Awarded the title of Advanced & High Technology Enterprise by Henan Science & Technology Department. Jinghua is the Vice president member of Sweet Potato Starch Professional Committee of China Starch Industry Association Units, the member of Potato Starch Professional Committee and the vice president member of China Food and Packaging Machinery Industry Association and Potato Food Processing Machinery Professional Committee Unit. Awarded the "ten years brilliant" honorary certificate issued by China international potato fair.
Jinghua company is an engineering and technical company specializing in starch engineering design, equipment manufacturing, engineering installation and debugging, technical personnel training and other work. Has two modern large factory, engineering and technical personnel more than 30 people, can provide installation services overseas .Company for China starch industry association executive director units, executive director of the association of Chinese cassava starch industry unit.
