Airflow Dryer 10t/H 269Kw Sweet Potato Starch Machine
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | DG-3.2 DG-4.0 DG-6.0 DG-10.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 10 sets/month |
|
Detail Information |
|||
| Product Name: | Airflow Dryer | Energy: | Electric |
|---|---|---|---|
| Power: | 269 Kw | Capacity: | 3-10 T/h |
| Service: | Overseas Installation | Machine: | Sweet Potato Starch Drying Machine |
| Advantage: | Long Working Time | Useful Life: | 20 Years |
| High Light: | 269Kw Sweet Potato Starch Machine,10t/H Sweet Potato Starch Machine,Potato Starch Airflow Dryer |
||
Product Description
Sweet Potato Starch Drying Machine 1 Year Warranty Good Effect Airflow Dryer
1.Description of sweet potato starch drying machine
When designed air flow drying system, we fully considered each factor of turbulent flow,cyclone separating and heat exchange etc., so that each collocation and parameter have definite theory basis, such as heat exchange's collocation , temperature control of inlet air and outlet air,diameter change of cyclone pipe etc. Through measuring on feeding material moisture,or temperature difference between inlet and outlet, the feeding quantity and inlet steam volume can be automatic adjusted, thus the water content of product could of product could reach the technology requirement.This kind airflow dryer is not only suitable to all kinds potato kinds starch to be dried,but also adaptable to the drying of corn starch and wheat starch.
Main technical parameters
| Model | DG-3.2 | DG-4.0 | DG-6.0 | DG-10.0 |
| Output(t/h) | 3.2 | 4.0 | 6.0 | 10.0 |
| Power capacity(Kw) | 97 | 139 | 166 | 269 |
| Moisture of wet starch(%) | ≤40 | ≤40 | ≤40 | ≤40 |
| Moisture of dry starch(%) | 12-14 | 12-14 | 12-14 | 12-14 |
The working principle of airflow dryer
The cold air enters the radiator plate through the air filter, and the hot air flow after heating enters the dry air pipe. Meanwhile, the wet material enters the hopper of the feeding unit from the wet starch inlet, and is transported into the hoist by the feeding winch.The hoist rotates at high speed to drop the wet material into the dry duct, so that the wet material is suspended in the high speed hot air stream and heat is exchanged.After the material is dried, it enters the cyclone separator with the airflow, and the separated dry material is discharged by wind winding, and the finished product is screened and packed into the warehouse. And the separated exhaust gas, by the exhaust fan into the exhaust gas duct, into the atmosphere.
2.Packing & Shipping
Packing : Customize the wooden case according to the size of the product.
Delivery: 14 days after receiving pre-payment (on time according to contract strictly).
3.FAQ
