960r/Min 45Kw Cassava Starch Slurry Fiber Centrifuge Sieve
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | DLS85 DLS100 DLS120 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 10 sets/month |
|
Detail Information |
|||
| Product Name: | Centrifuge Sieve | Service: | Overseas Installation |
|---|---|---|---|
| Application: | Cassava Starch Slurry Fiber Separator Plant | Dimension: | 1640*2490*2222 Mm |
| Weight: | 2200 Kg | Power: | 45 Kw |
| Useful Life: | 20 Years | Condition: | New |
| Highlight: | Cassava Starch Centrifuge Sieve,960r/Min Centrifuge Sieve,Cassava Starch Slurry Separator |
||
Product Description
Cassava Starch Slurry Fiber Separator Processing Equipment 2200 Kg Centrifuge Sieve
Description of cassava starch slurry fiber separator machine
The pulp after rasping is pumped to the sieve section – centrifuge sieve group, under the action of gravity and centrifugal force, the pulp along the sieve surface to do circular motion. Reasonably use the process water, clean water and the sieve to maximally separate the starch out of pulp. The fiber slurry is transported to the fiber dehydrator for dewatering by physical extrusion way. After sieving, the starch milk is pumped to the fine fiber sieve to further separate out the fine fibers in the starch milk.
Main technical parameters
|
Model
|
Basket diameter(mm) | Main shaft speed(r/min) | Working model |
Power (Kw) |
Dimension (mm) |
Weight (t) |
| DLS85 | 850 | 1050 | continuous | 18.5/22/30 | 1200x2111x1763 | 1.5 |
| DLS100 | 1000 | 1050 | continuous | 22/30/37 | 1440x2260x1983 | 1.8 |
| DLS120 | 1200 | 960 | continuous | 30/37/45 | 1640x2490x2222 | 2.2 |
Advantages of centrifuge sieve
1. Combining the latest technology and years’ experience into a whole.
2. Key components introduced abroad, lone service life, low maintenance cost.
3. All parts contact with material are stainless steel, no material contamination.
4. Sieve basket is calibrated through dynamic equilibrium by domestic authority body.
5. Sieve made from laser perforating on titanium alloy plate.
6. To facilitate the automatic design for centrifugal sieve group, CIP system and chain automatic control can be easily realized.
7. Advanced surface treatment technology ensuring the good appearance and resistance of oil and dirt.
Packing & Shipping
Packing & Shipping: Customize the wooden case according to the size of the product.
Delivery: 14 days after receiving pre-payment (on time according to contract strictly).
Our Service
Pre-sale service
1.Introducing detail features and application of the products to customer.
2.Selecting economical and practical machines for customer.
3.Providing operation data of the related machine.
4.Providing means of trial performance for customer.
5.Flow chart and factory designing layout .
Sale service
1.Recommending engineering conditions required for installation of the machine.
2.Communicating the manufacturing progress of machines with customer in time.
3.Project planning and design services.
After-sale service
1.Training of equipment maintenance and operating personally.
2.Installation and commissioning of equipment until everything is functional.
3.One year warranty and providing long-term maintenance service and spare parts.
4.Giving technical support to customer for developing new product.
5.Engineers available to serve machinery overseas.
