Food Grade Cassava Starch Production Line Hydrocyclone Equipment
Product Details:
| Place of Origin: | Henan |
| Brand Name: | JingHua |
| Model Number: | Hydrocyclone |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | 5500*1500*3500 mm |
| Delivery Time: | 10 work days |
| Payment Terms: | L/C, D/P, D/A, Western Union, T/T, MoneyGram |
| Supply Ability: | 10 |
|
Detail Information |
|||
| Product Name: | Hydrocyclone Equipment | Function: | Multifunction Flour Grinder |
|---|---|---|---|
| Application: | Food Industry Machinery | After-sales Service Provided: | Service Machinery Overs |
| Usage: | Powder Milling | Type: | Food Processing Machine |
| Advantage: | High Effective | Capacity: | 5t/h |
| Highlight: | Food Grade Cassava Starch Production Line,Cassava Starch Hydrocyclone Equipment,5t/h Cassava Starch Hydrocyclone Equipment |
||
Product Description
Application of hydrocyclone
Zhengzhou jinghua starch hydro cyclone is used to each kind of starch and modified starch emulsion degreasing, fine slag separation, protein
separation, washing and enrichment, etc. Continuous concentration and separation of food industry suspension, clarification, etc.
Technical parameters of hydrocyclone
|
Model |
XL325 |
XL438 |
XL516 |
XLS426 |
|
|
Plate quantity |
1 |
1 |
1 |
2 |
Group capacity: 3-12t/h
7.5-45kw/stage
Total weight: 0.3t/stage |
|
Cylinder diameter(mm) |
362 |
438 |
516 |
426 |
|
|
Cylinder norm(mm) |
10,15 |
10,15 |
10,15 |
10,15 |
|
|
Feed Pressure(MPa) |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
0.6-0.8 |
|
|
Inlet Size(mm) |
76 |
89 |
89 |
2* 89 |
|
|
Underflow Size(mm) |
48 |
48 |
57 |
76 |
|
|
Top flow Size(mm) |
57 |
57 |
76 |
2- 57 |
Working principle
Starch milk enters the middle cavity of the cylinder body through the starch pump from the feeding port of the cyclone. Starch paste enters the
inlet of the cyclone tube and enters the inner part of the cyclone tube along the tangent direction of the cyclone tube. In the swirl tube, the material
components rotate according to the spiral line and generate centrifugal force. And relative density of small proteins and water centrifugal force is
small, the spiral motion, is reduced to about the lower part of the cone resistance by bottom LiuKou formed in the reverse direction of rotation of
the spiral vortex uplink to LiuKou eduction, so as to achieve the purpose of each one.
Our Services
Pre-sale service
1. Introduce the features and applications of the products to customers in detail.
2. Choose economical and practical machines for customers.
3. Provide relevant machine operation data.
4. Provide customers with the means of trial operation.
5. Flow chart and factory design plan.
Discount sale service
1. Recommend the engineering conditions required for installing the machine.
2. Timely communicate with customers about the manufacturing progress of the machine.
3. Project planning and design services.
After-sales service
1. Equipment maintenance and operation training.
2. Installation and commissioning of equipment until everything is normal.
3. One year warranty, and provide long-term maintenance services and spare parts.
4. Provide technical support for customers to develop new products.
5. Engineers can be sent overseas to repair machinery.
6. Provide installation/operation/service/maintenance manuals in English.
Frequently Asked Questions
Are you a factory or a trading company?
A: Our company is a factory in Henan Province with an export license. We have been engaged in the export business for more than 20 years.
Q2. What is your main business?
A: Zhengzhou Jinghua is a company specializing in the production of starch processing machinery. Starch processing line, such as: cassava
starch production line, cassava flour production line, potato starch production line, sweet potato production line, wheat starch production line,
sago production line, garri production line
Where is your factory located? How do I get there?
A: Our address: Intersection of Zhengyun Road and Guanggu Road, Guangwu Town, Zhengzhou City, Henan Province, China.
Warmly welcome your presence!
Can you trust your products?
A: Our machines have passed ISO9001:2001 quality management system certification, and passed SGS, TUV CE certification.
If we show you the layout of the factory, can you help us design the entire production line?
A: Yes, our experienced engineers and technicians can help you arrange the layout and installation of the entire process line according to your
actual situation;
If we have a sample of the new product, can you help us analyze and design the machine?
A: Yes, our technical department can help you analyze, design and test your new products.
