1200 Kg Sweet Potato Rasper Equipment Sweet Potato Starch Production Line

1200 Kg Sweet Potato Rasper Equipment Sweet Potato Starch Production Line

Product Details:

Place of Origin: Henan
Brand Name: JingHua
Model Number: Rasper Equipment

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: 3000*1590*1500 mm
Delivery Time: 10 work days
Payment Terms: L/C, D/P, D/A, Western Union, T/T, MoneyGram
Supply Ability: 10
Get Best Price Contact Now

Detail Information

Product Name: Rasper Equipment Energy: Electric
Material: Stainless Steel Quality: Top Level
Advantage: Large Capacity Operation: Automatic
Application: Cassava Cutting Equipment Processing Type: Cleaning-milling-packing
Highlight:

sweet potato rasper equipment

,

1200Kg sweet potato rasper equipment

,

electric Sweet Potato Starch Production Line

Product Description

Product Description


Introduction of sweet potato grinder machine



Sweet potato starch is mainly stored in the fleshy part of the root, the raw material particles are relatively large, the internal tissue is not easy to



destroy, the use of multiple filing, fully destroy the potato block structure, can make small starch particles can be smoothly free from the root,



improve the extraction rate of starch.



Key Technology & Innovation Potions



1. All parts in contact with raw materials are made of food-grade stainless steel to protect materials from external contamination.


2. High speed, fast line speed, good grinding performance, uniform particles, high starch ionization rate.


3. The rotor is calibrated by international advanced dynamic balance instrument, which meets G1 standard.


4. Parts (such as bearings) are imported from Europe for longer service life


5. Unique sieving gear makes disassembly easy.


6. Saw blade is made of special steel by special process, with high hardness and wear resistance.


7. The casting is made of high chromium cast iron with a hardness of HRC60 and excellent wear resistance.


8. Unique drum groove and layered instrument design, conducive to saw blade replacement.



Main technical parameters



Model

DCM8435

DCM8450

DCM8465

DCM1070

Main shaft rotating speed(r/min)

2100

2100

2100

1470

Drum diameter(mm)

Φ840

Φ840

Φ840

Φ1100

Drum width(mm)

350

500

650

700

Power(Kw)

110

160

200

250

Capacity(t/h)

20-23

30-33

35-40

40-45

Dimension(mm)

2170x1260x1220

2170x1385x1250

2170x1650x1380

3000x1590x1500



The working principle of rasper



The material enters into the body of the file mill shell through the upper entrance, and is broken by the impact, shear and grinding effect of the



saw blade moving at high speed. The lower part of the rotor is equipped with a screen screen. The material smaller than the size of the screen



hole is discharged through the screen plate, and the particles larger than the size of the screen hole are blocked and remain on the screen plate



to continue to be hit and grinder by the saw blade.



Our Services


Pre-sale service


1. Introduce the features and applications of the products to customers in detail.


2. Choose economical and practical machines for customers.


3. Provide relevant machine operation data.


4. Provide customers with the means of trial operation.


5. Flow chart and factory design plan.



Sales service


1. Recommend the engineering conditions required for installing the machine.


2. Timely communicate with customers about the manufacturing progress of the machine.


3. Project planning and design services.



After-sales service


1. Equipment maintenance and operation training.


2. Installation and commissioning of equipment until everything is normal.


3. One year warranty, and provide long-term maintenance services and spare parts.


4. Provide technical support for customers to develop new products.


5. Engineers can be sent overseas to repair machinery.


FAQ


Q1: Is your company a factory or trading company?


A: Our company is a factory in Henan Province ,with export license and we have done export business over 20 years professionally.



Q2.What is your main business?


A: Zhengzhou jinghua is devoted to starch processing machine. The machine of starch processing line , such as : cassava starch line , cassava



flour line , potato starch line , sweet potato line , wheat starch ,sago line and garri line



Q3:Where is your factory located? How can I visit there?


A: Our add: Zhengyun Road and Guanggu Road intersection , Guangwu Town , Zhengzhou City , Henan Province , China.


Warmly welcome to visit us!


Q4: Are your products can be assured ?


A: Our machines are all passed ISO9001:2001 and have CE certificate by SGS, TUV.


Q5: If we show you our layout of factory, can you help us to design the whole process line?


A : Yes, our experienced engineers and technical employees can help you to arrange the layout and installation of whole process line based on



your real situation;


Q6: If we have samples of new products, can you help us to analysis and design the machine?


A: Yes, Our technical department can help you to analysis, design and test the new products you offered.
