2.2kw 11t/H Sieve Cassava Flour Processing Equipment
Product Details:
| Place of Origin: | Zhengzhou City,China |
| Brand Name: | JINGHUA |
| Certification: | CE |
| Model Number: | GDS4*10*83 GDS2*10*83 GDS1*10*83 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Customize the wooden case according to the size of the product，Each container can hold 4-6 pieces of products |
| Delivery Time: | 5-14 work days after receiving pre payment |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 20 sets/month |
|
Detail Information |
|||
| Product Description: | Half Closed Flour Sifter | Useful Life: | 20 Years |
|---|---|---|---|
| Customized: | Customized | Energy: | Electric |
| Line: | Cassava Flour Production Line | Installation: | Yes |
| Capacity: | 11 T/h | Weight: | 1520 Kg |
| High Light: | 11T/H Cassava Flour Processing Equipment,Half Closed Flour Sieve Machine,2.2kw Cassava Starch Sifter |
||
Product Description
Cassava Flour Processing Equipment Electric 11 T/H Half Closed Flour Sieve Machine
1.Product Description
Zhengzhou jinghua starch sifter is widely used in starch industry and it is proved the best sifter in starch sifting.It is widely used for sieving dry starch before starch packing in corn starch, cassava starch, potato starch and sweet potato starch and wheat starch sago starch processing project.
Working principle
The drive unit with counter balance weight, with motor, pulleys, v-belt is mounted under the cabinet box section, adjustable to suit different applications. Material is fed into the top and by the machines circular motion, the fine material moves through the sieve mesh and is discharged out each sieve side to outlets, while the course material over tails and sent to separate outlets.
Main technical parameters
| Model |
Bin (piece) |
Sifter area (㎡) |
Capacity (t/h) |
Power (kw) |
Weight (kg) |
Dimension (mm) |
| GDS4*10*83 | 4 | 18 | 10～11 | 2.2 | 1520 | 2310×2200×2400 |
| GDS2*10*100 | 2 | 10 | 6～8 | 1.5 | 900 | 2600×1650×2220 |
| GDS2*10*83 | 2 | 8.5 | 5～6 | 1.5 | 850 | 2120×1400×2220 |
| GDS1*10*100 | 1 | 6.6 | 3～4 | 1.1 | 750 | 1610×1610×1800 |
| GDS1*10*83 | 1 | 4.2 | 2.5～3 | 0.75 | 600 | 1400×1400×1800 |
2.Packing & Shipping
Packing & Shipping: Customize the wooden case according to the size of the product.
Delivery: 14 days after receiving pre-payment (on time according to contract strictly).
3.Our Service
Pre-sale service
1.Introducing detail features and application of the products to customer.
2.Selecting economical and practical machines for customer.
3.Providing operation data of the related machine.
4.Providing means of trial performance for customer.
5.Flow chart and factory designing layout .
Sale service
1.Recommending engineering conditions required for installation of the machine.
2.Communicating the manufacturing progress of machines with customer in time.
3.Project planning and design services.
After-sale service
1.Training of equipment maintenance and operating personally.
2.Installation and commissioning of equipment until everything is functional.
3.One year warranty and providing long-term maintenance service and spare parts.
4.Giving technical support to customer for developing new product.
5.Engineers available to serve machinery overseas.
